Fun with Spheres Fractals

• Recursively repeat spheres (and circles) along the x, y and z axis - at each recursion we scale and offset the sphere.
• Visualize the fractal as 2d in HTML canvas and in 3d using ray-tracing (WebGL and WebGPU)
• As the pattern is a fractal - the detail is limitless but also costly (from a few hundred to a few hundred thousand spheres depending how many recursions)

Simple 2D Example

Can you make a fractal from just spheres? Absolutely, and it's every bit as mesmerizing as you might imagine. Fractals are complex patterns that exhibit self-similarity, meaning they look the same at any scale.

The sphere fractal presented here works by by repeating a simple shape like a circle, but each time you repeat the shape, you make it smaller and place it in specific spots around the original. This keeps repeating creating a never-ending pattern that looks the same no matter how much you zoom in, and it all happens thanks to some nifty recursive math!

We implement a simple 2d version of this using a

circlefractal

function. The function calls itself (i.e., recursively) to add smaller and smaller cirles inside and outside the parent circle to create a mesmerizing layout.

The concept and code is very simple - but the results are very beautiful and mezmorizing.

The implementation is given below in JavaScript and HTML canvas.

The sphere fractal obeys the self-similarity rule of fractals - which means that no matter how much you zoom in on the pattern, you will find smaller versions of the same shape.

<?php
document.body.style.backgroundColor = 'white';
var canvas = document.createElement('canvas');
document.body.appendChild( canvas );
canvas.width = canvas.height = 512;

var context = canvas.getContext("2d");

// Define the circle parameters
var centerX = canvas.width / 2;
var centerY = canvas.height / 2;

const ellipse = (centerX,centerY,radius) => {
    // Begin the path for the circle
    context.beginPath();
    context.arc(centerX, centerY, radius*0.5, 0, 2 * Math.PI, false);

    // Fill the circle with color
    context.fillStyle = "rgba(128,0,0,0.5)";
    context.fill();

    // Stroke the circle's outline
    context.lineWidth = 2;
    context.strokeStyle = "black";
    context.stroke();
}

const circlefractal= (x,y,s) => {
  if ( s < 20 ) return;

  ellipse(x,y,s);

  /// smaller inside the main circle
  circlefractal(x + (s/3), y, s/3);
  circlefractal(x - (s/3), y, s/3);
  circlefractal(x,         y+(s/3), s/3);
  circlefractal(x,         y-(s/3), s/3);

  // smaller outside the main circle
  circlefractal(x + (2*s/3), y, s/3);
  circlefractal(x - (2*s/3), y, s/3);
  circlefractal(x,           y + (2*s/3), s/3);
  circlefractal(x,           y - (2*s/3), s/3);
}

circlefractal( 250, 250, 200 );

document.body.style.backgroundColor = 'white';
var canvas = document.createElement('canvas');
document.body.appendChild( canvas );
canvas.width = canvas.height = 512;

var context = canvas.getContext("2d");

// Define the circle parameters
var centerX = canvas.width / 2;
var centerY = canvas.height / 2;

const ellipse = (centerX,centerY,radius) => {
    // Begin the path for the circle
    context.beginPath();
    context.arc(centerX, centerY, radius*0.5, 0, 2 * Math.PI, false);

    // Fill the circle with color
    context.fillStyle = "rgba(128,0,0,0.5)";
    context.fill();

    // Stroke the circle's outline
    context.lineWidth = 2;
    context.strokeStyle = "black";
    context.stroke();
}

const circlefractal= (x,y,s) => {
  if ( s < 20 ) return;

  ellipse(x,y,s);

  /// smaller inside the main circle
  circlefractal(x + (s/3), y, s/3);
  circlefractal(x - (s/3), y, s/3);
  circlefractal(x,         y+(s/3), s/3);
  circlefractal(x,         y-(s/3), s/3);

  // smaller outside the main circle
  circlefractal(x + (2*s/3), y, s/3);
  circlefractal(x - (2*s/3), y, s/3);
  circlefractal(x,           y + (2*s/3), s/3);
  circlefractal(x,           y - (2*s/3), s/3);
}

circlefractal( 250, 250, 200 );

Ramp up the detail to further recursive depth and more spheres.

2d to 3d (circles to spheres)

When extended into 3D we'll extend the algorithm to include a `z-value` - which repeats in the same way as the x and y axis. For the 3d example, we'll use ray-tracing (WebGL and WebGPU). We can create the spheres in JavaScript and pass them through to the ray-tracer. We'll use fractals so we can add mirror effects!

Ray-traced the sphere fractal of different levels.

We've implemented the example in both WebGL and WebGPU. The spheres positions and radius are generate in JavaScript and passed across to the fragment shader for ray-tracing.

For the 3d version - we'll only show the spheres on the outside (not the inside ones as we did with the 2d version).

<?php
let spheres = [];
const buildSphereFractal = (x,y,z,r) => {
    if ( r < 0.01 ) return;

    spheres.push( { x, y, z, r:r*0.5 } );

    // smaller outside the main circle
    buildSphereFractal(x + (2*r/3), y,           z,           r/3);
    buildSphereFractal(x - (2*r/3), y,           z,           r/3);
    buildSphereFractal(x,           y + (2*r/3), z,           r/3);
    buildSphereFractal(x,           y - (2*r/3), z,           r/3);
    buildSphereFractal(x,           y,           z + (2*r/3), r/3);
    buildSphereFractal(x,           y,           z - (2*r/3), r/3);
}
buildSphereFractal(0,0,0,1);
console.log('num spheres:', spheres.length );

let spheres = [];
const buildSphereFractal = (x,y,z,r) => {
    if ( r < 0.01 ) return;

    spheres.push( { x, y, z, r:r*0.5 } );

    // smaller outside the main circle
    buildSphereFractal(x + (2*r/3), y,           z,           r/3);
    buildSphereFractal(x - (2*r/3), y,           z,           r/3);
    buildSphereFractal(x,           y + (2*r/3), z,           r/3);
    buildSphereFractal(x,           y - (2*r/3), z,           r/3);
    buildSphereFractal(x,           y,           z + (2*r/3), r/3);
    buildSphereFractal(x,           y,           z - (2*r/3), r/3);
}
buildSphereFractal(0,0,0,1);
console.log('num spheres:', spheres.length );

• WebGL - we pass the fractal spheres across using a

uniform

buffer.
• WebGPU - we pass the fractal spheres across using a

gpu

buffer.

The links for the interactive versions are given at the bottom. They're drawn using a classical ray-tracing algorithm with recursion for the reflective vector.

WebGPU Buffer

The WebGPU buffer is implemented as using the following code:

<?php
const MAX_SPHERES = 1600;
const sphereData  = new Float32Array( MAX_SPHERES * 4 );
const spheresUniformBuffer = device.createBuffer({size: sphereData.byteLength, usage: GPUBufferUsage.UNIFORM | GPUBufferUsage.COPY_DST });
for (let i=0; i<spheres.length; i++)
{
    sphereData[i*4+0] = spheres[i].x;
    sphereData[i*4+1] = spheres[i].y;
    sphereData[i*4+2] = spheres[i].z;
    sphereData[i*4+3] = spheres[i].r;
}
device.queue.writeBuffer(spheresUniformBuffer, 0, sphereData );

const MAX_SPHERES = 1600;
const sphereData  = new Float32Array( MAX_SPHERES * 4 );
const spheresUniformBuffer = device.createBuffer({size: sphereData.byteLength, usage: GPUBufferUsage.UNIFORM | GPUBufferUsage.COPY_DST });
for (let i=0; i<spheres.length; i++)
{
    sphereData[i*4+0] = spheres[i].x;
    sphereData[i*4+1] = spheres[i].y;
    sphereData[i*4+2] = spheres[i].z;
    sphereData[i*4+3] = spheres[i].r;
}
device.queue.writeBuffer(spheresUniformBuffer, 0, sphereData );

In the fragment shader we can access the array of sphere as follows (wgls fragment shader):

<?php
const NUM_SPHERES:i32 = 1555;
const MAX_SPHERES:i32 = 1600;
@group(0) @binding(2) var <uniform> myspheres    : array<vec4<f32>, MAX_SPHERES>;

const NUM_SPHERES:i32 = 1555;
const MAX_SPHERES:i32 = 1600;
@group(0) @binding(2) var <uniform> myspheres : array<vec4<f32>, MAX_SPHERES>;

The example WebGPU/GL implementations use hard coded constants for the numer of spheres.

Resources & Links

• Canvas 2D Fractal Spheres Example

• WebGL Ray-Traced Example

• WebGPU 3d Ray-Traced Example

A slower version of the example that generates the spheres for the fractal on the fragment shader - we implementing the code for calculating all the spheres (sizes and positions) on the fragment shader. You can't use recursion on the GPU with GLSL or (WGSL) so we use a (custom stack) to acomplish this. Slower and requires the shader generate the fractal on each fragment each frame - but was done for educational purposes (fractal shader generator version)
