Userscripts are a little secret that lets you run scripts on specific web pages to do your bidding and make your life easier - ...
Userscripts are a little secret that lets you run scripts on specific web pages to do your bidding and make your life easier - fun images are from from 'Rick and Morty' - Userscripts turn you into a Rick (a super genius).


Upgrading Old WebGPU and WGSL Scripts (Syntax Fixes)



WebGPU is new (very new) and as you'd would expect it has gone through a few updates to the language since it was released to the public - nothing major - just some tweaks and refinements to the syntax (both the API and the WGSL shaders).

As I've written hundreds of scripts - I wanted a quick way to upgrade any outdated versions - without having to manually go through them and fix the lines. The fixes aren't major - but it's time consuming if you've got lots and lots of scripts.

So this article gives a userscript with a bit of regular expression search/replace - to fix any WebGPU scripts on a page that are located in a textarea block.

The script isn't perfect - but it works with most of my examples - and you can easily take it further if you want. I didn't want to write a full language tokenizer/parser - just look for common language changes (e.g.
[[blocks]]
is no longer used). Search for these old styles and upgrade them.


Key points:
• Userscript uses the TamperMonkey browser extension
• Hardcoded regular expressions
• Timeout startup (waits 2 seconds before launching on new pages)
• Adds fixed button to the page (top left)
• Only replace scripts in 'textarea' (does not give any warnings or options)


Complete Code


// ==UserScript==
// @name         WebGPU and WGSL Upgrader Fixer Userscript
// @namespace    http://tampermonkey.net/
// @version      2024-06-24
// @description  WebGPU and WGSL Syntax and Function Upgrade Fixer Early Releases
// @author       You
// @match        https://*/*
// @icon         https://www.google.com/s2/favicons?sz=64&domain=xbdev.net
// @grant        none
// ==/UserScript==

function updatewebgpuscript(txt)
{
    let newpresformat2 = `
//const presentationFormat = context.getPreferredFormat(adapter); - no longer supported
const presentationFormat = navigator.gpu.getPreferredCanvasFormat();
`;

    let newpresformat = `navigator.gpu.getPreferredCanvasFormat(); // context.getPreferredFormat(adapter); - no longer supported`;

    txt = txt.replaceAll(/context.getPreferredFormat\(adapter\);/g, newpresformat);

    txt = txt.replaceAll(/window.devicePixelRatio/g, '1'); // window.devicePixelRatio => 1

    txt = txt.replaceAll(/stencilLoadValue/g, '// stencilLoadValue');
    txt = txt.replaceAll(/stencilStoreOp/g,   '// stencilStoreOp');

    // loadValue -> clearValue
    txt = txt.replaceAll(/loadValue/g, 'loadOp:"clear", clearValue');
    // endPass() -> end()
    txt = txt.replaceAll(/endPass\(\)/g, 'end()');
    // stage
    txt = txt.replaceAll(/\[\[stage\(vertex\)\]\]/g, '@stage(vertex)');
    txt = txt.replaceAll(/\[\[stage\(fragment\)\]\]/g, '@stage(fragment)');
    txt = txt.replaceAll(/\[\[stage\(compute\)\]\]/g, '@stage(compute)');
    // builtin - [[builtin(position)]] changed to @builtin(position)
    txt = txt.replaceAll(/\[\[builtin\(([a-zA-Z_]*)\)\]\]/g, '@builtin($1)');
    // [[group(0), binding(0)]] var mySampler: sampler; -> @group(0) @binding(0) var mySampler: sampler;
    txt = txt.replaceAll(/\[\[group\((\w)\), binding\((\w)\)\]\]/g, '@group($1) @binding($2)');
    txt = txt.replaceAll(/\[\[binding\((\w)\), group\((\w)\)\]\]/g, '@binding($1) @group($2)');
    // [[location(0)]] -> @location(0)
    txt = txt.replaceAll(/\[\[location\((\w)\)\]\]/g, '@location($1)');
    // smoothstep
    txt = txt.replaceAll(/fn smoothstep/g, 'fn mysmoothstep');
    // depthLoadValue -> depthLoadOp and depthClearValue
    txt = txt.replaceAll(/depthLoadValue/g, 'depthLoadOp:"clear", depthClearValue');
    //
    txt = txt.replaceAll(/(context.configure\(\{ device : device,)/g, '$1 compositingAlphaMode: "opaque",');
    //
    // [[stage(compute), workgroup_size(8, 8)]]
    txt = txt.replaceAll(/\[\[stage\(([a-zA-Z_]*)\), workgroup_size\(([a-zA-Z_0-9, ]*)\)\]\]/g, '@stage($1) @workgroup_size($2)');
    // [[stride(16)]] -> ''
    txt = txt.replaceAll(/\[\[stride\([0-9]*\)\]\]/g, '');
    // @location(1) iIdx: u32 -> @location(1) @interpolate(flat) iIdx: u32
    txt = txt.replaceAll(/(@location\([0-9]*\)[ ]*?)([a-zA-Z_0-9]*[ ]*?:[ ]*?u32)/g, '$1 @interpolate(flat) $2');


    // remove [[block]]
    txt = txt.replaceAll(/\[\[block\]\]/g, '');


    // remove struct block listing (save them for later)
    // semicolons -> commas
    const regexp = /struct [a-zA-Z0-9_]* \{((.|[\r\n])*?)\}/g;
    const array  = [...txt.matchAll(regexp)];
    txt = txt.replace(/struct [a-zA-Z0-9_]* \{((.|[\r\n])*?)\}/g, '{STRUCT}' );

    // Restore struct blocks with added wrapping
    for (let i=0; i<array.length; i++)
    {   let arr = array[i][0].replaceAll(';', ',');
        txt = txt.replace(/(\{STRUCT\})/, arr );
    }// end for i



    txt = txt.replaceAll(/@stage\(vertex\)/g,   '@vertex');
    txt = txt.replaceAll(/@stage\(fragment\)/g, '@fragment');
    txt = txt.replaceAll(/@stage\(compute\)/g,  '@compute');

    txt = txt.replaceAll(/\.dispatch\(/g,  '.dispatchWorkgroups(');

    return txt;
}

function setupWebGPUFix()
{
//(function() {
    'use strict';

    console.log('hell0');
    // Function to replace text in all textareas
    function replaceText() {
        console.log('replaceText called');
        // Find all textarea elements
        const textareas = document.querySelectorAll('textarea');
        if (textareas.length > 0) {
            textareas.forEach(textarea => {
                console.log('text area...');
                // Replace occurrences of 'catslikemilk' with 'nomilk'
                //textarea.value = textarea.value.replace(/catslikemilk/g, 'nomilk');

                textarea.value = updatewebgpuscript( textarea.value );

                var event2 = new Event('input', { bubbles: true });
                textarea.dispatchEvent(event2);
                textarea.parentNode.dispatchEvent(event2);

            });
        } else {
            console.log('No textareas found');
        }
    }

    // Create a button
    const button = document.createElement('button');
    button.textContent = 'Fix & Replace WebGPU WGSL Text';
    button.style.position = 'fixed';
    button.style.top = '10px';
    button.style.left = '10px';
    button.style.zIndex = 10000;

    // Add click event to button
    button.addEventListener('click', replaceText);

    // Append button to body
    document.body.appendChild(button);
//})();
}

setTimeout(setupWebGPUFix, 2000);


Things to Try


The example shows a quick and dirty prototype to make my life easier - and can be used on examples you stumble across on the web if you want to do a quick update. Few ideas if you want to develop the prototype further:

• Extract the script and put into a popup dialog - highlight the lines that are going to be changed
• Include an 'option' dialog to select which language features to upgrade
• Extract the script, upgrade it, and put it into a new textarea (does not replace the original version)
• Split the text into API (JS) and the WGSL components - run the JS through Lint checker, and the WGSL through the WebGPU API compiler




Resources and Links


• Regular Expressions [LINK]
• WebGPU Lab [LINK]
• Usersripts Tutorial/Example [LINK]
