/* File: md2.cpp
*/
/* Author: bkenwright@xbdev.net
*/
/* Date:
10-11-2002
*/
/*
*/
/***************************************************************************/
// This file holds our self contained .md2 (quake2) class for loading in and
// displaying our .md2 file in directX3D.
struct
stMd2Header
{
int magic;
// The magic number used to identify the file.
int version;
// The file version number (must be 8).
int skinWidth;
// The width in pixels of our image.
int skinHeight;
// The height in pixels of our image.
int frameSize;
// The size in bytes the frames are.
int numSkins;
// The number of skins associated with the model.
int numVertices;
// The number of vertices.
int numTexCoords;
// The number of texture coordinates.
int numTriangles;
// The number of faces (polygons).
int numGlCommands;
// The number of gl commands.
int numFrames;
// The number of animated frames.
int offsetSkins;
// The offset in the file for the skin data.
int offsetTexCoords;//
The offset in the file for the texture data.
int offsetTriangles;//
The offset in the file for the face data.
int offsetFrames;
// The offset in the file for the frames data.
int offsetGlCommands;//
The offset in the file for the gl commands data.
int offsetEnd;
// The end of the file offset.
};
// Some structures to hold or read in data in.
struct
stMd2Skins
{
char skinName[64];
};
struct
stMd2TexCoords
{
short u, v;
};
struct
stMd2Triangles
{
short vertexIndex[3];
short texIndex[3];
};
struct
stMd2Vertices
{
float vertex[3];
float normal[3];
};
struct
stMd2Frames
{
char name[16];
stMd2Vertices* pFinalVerts;
};
// These two variables are declared in dxdraw.cpp thats why they have the
// extern keyword in front of them.
extern
LPDIRECT3D8 g_pD3D;
extern
LPDIRECT3DDEVICE8 g_pD3DDevice;
struct
stKeyFrame
{
int start;
int end;
char szName[16];
};
struct
stKey
{
int numKeys;
stKeyFrame *pKey;
};
// Our DirectX3D structure definition.
struct
my_vertex
{
FLOAT x, y, z; // D3DFVF_XYZ
FLOAT tu, tv; // D3DFVF_TEX1
};
/***************************************************************************/
/*
*/
/* The CLoadMD2 class, yup its name speaks for itself, it loads the 3D
*/
/* model data from the .md2 file and then we can access its public data
*/
/* variables to use the data.
*/
/*
*/
/***************************************************************************/
class
CMD2X
{
public:
CMD2X(){ m_vertex_description = (D3DFVF_XYZ | D3DFVF_TEX1); };
~CMD2X(){};
public:
bool ImportMD2(char*
szFileName, char* szTexName);
void Release();
void RenderFrame();
void Animate(UINT iAnimKey);
protected:
void ReadMD2Data();
void SetUpFrames();
void SetUpDX();
bool Timer(float*
t);
void SetDXVertices(UINT iAnimKey);
FILE* m_fp;
protected:
stMd2Header m_Md2Header;
stMd2Skins *m_pSkins;
stMd2Triangles *m_pTriangles;
stMd2TexCoords *m_pTexCoords;
stMd2Frames *m_pFrames;
protected:
stKey m_Keys;
int m_curFrame;
int m_nextFrame;
int m_curAnimKey;
protected:
float m_lastTime;
float m_elapsedTime;
protected://
dx variables
UINT m_vertex_description;
IDirect3DTexture8* m_pTexture;
IDirect3DVertexBuffer8 * m_vb; // vertex buffer
};
/***************************************************************************/
/*
*/
/* The action implimentations of our CLoadMD2 class.
*/
/*
*/
/***************************************************************************/
bool
CMD2X::ImportMD2(char* szFileName,
char* szTexName)
{
m_fp = fopen(szFileName, "rb");
ReadMD2Data();
SetUpFrames();
SetUpDX();
fclose(m_fp);
// Load or textures into our DX.
D3DXCreateTextureFromFile(g_pD3DDevice, szTexName, &m_pTexture);
return true;
}
void
CMD2X::ReadMD2Data()
{
fread(&m_Md2Header, 1, sizeof(m_Md2Header),
m_fp);
// Allocate memory for our data so we can read it
in.
m_pSkins = new stMd2Skins [
m_Md2Header.numSkins ];
m_pTexCoords = new stMd2TexCoords[
m_Md2Header.numTexCoords ];
m_pTriangles = new stMd2Triangles[
m_Md2Header.numTriangles ];
m_pFrames = new stMd2Frames [
m_Md2Header.numFrames ];
// -1- Seek to the start of our skins name data
and read it in.
fseek(m_fp, m_Md2Header.offsetSkins, SEEK_SET);
fread(m_pSkins, sizeof(stMd2Skins),
m_Md2Header.numSkins, m_fp);
// -2- Seek to the start of our Texture Coord data
and read it in.
fseek(m_fp, m_Md2Header.offsetTexCoords, SEEK_SET);
fread(m_pTexCoords, sizeof(stMd2TexCoords),
m_Md2Header.numTexCoords, m_fp);
// -3- Seek to the start of the Triangle(e.g.
Faces) data and read that in.
fseek(m_fp, m_Md2Header.offsetTriangles, SEEK_SET);
fread(m_pTriangles, sizeof(stMd2Triangles),
m_Md2Header.numTriangles, m_fp);
// -4- Finally lets read in "one" of the frames,
the first one.!
struct stAliasVerts
{
byte vertex[3]; // an index reference
into the location of our vertexs
byte lightNormalIndex; // in index
into which
tex
coords to use.
};
struct stAliasFrame
{
float scale[3];
float translate[3];
char name[16];
stAliasVerts aliasVerts[1];
};
unsigned char
largebuffer[50000];
stAliasFrame* pTempFrame = (stAliasFrame*) largebuffer;
fseek(m_fp, m_Md2Header.offsetFrames, SEEK_SET);
for(int
iFrame=0; iFrame< m_Md2Header.numFrames; iFrame++)
{
fread(pTempFrame, 1, m_Md2Header.frameSize, m_fp);
// We have read in all the frame data here (into a
temporyary!!..eeEKK)..
m_pFrames[iFrame].pFinalVerts = new
stMd2Vertices[ m_Md2Header.numVertices ];
strcpy( m_pFrames[iFrame].name, pTempFrame->name );
// CONVERSION! A few things before we
can use our read in values,
// for some reason the Z and Y need to
be swapped, as Z is facing up
// and Y is facing into the screen.
// Also our texture coordinates values
are between 0 and 256, we just
// divide them all by 256 which makes
them between 0 and 1.
// Swap Z<->Y
for(int
i=0; i< m_Md2Header.numVertices; i++)
{
m_pFrames[iFrame].pFinalVerts[i].vertex[0] = pTempFrame->aliasVerts[i].vertex[0]
* pTempFrame->scale[0]
+ pTempFrame->translate[0];
// x
m_pFrames[iFrame].pFinalVerts[i].vertex[2] = -1*(pTempFrame->aliasVerts[i].vertex[1]
* pTempFrame->scale[1]
+ pTempFrame->translate[1]); //
z
m_pFrames[iFrame].pFinalVerts[i].vertex[1] = pTempFrame->aliasVerts[i].vertex[2]
* pTempFrame->scale[2]
+ pTempFrame->translate[2];
// y
}
}
// Scale Textures.
for (int
j=0; j< m_Md2Header.numTexCoords; j++)
{
// WARNING.. you can't put a decimal
number into a short...e.g.
// you can't put 0.1 into a unsigned
short int, it will be changed to 0.
/*
m_pTexCoords[j].u = m_pTexCoords[j].u ;// 256;
//float(m_Md2Header.skinWidth);
m_pTexCoords[j].v = m_pTexCoords[j].v ;// 256;
//float(m_Md2Header.skinHeight);
*/
}
}
void
CMD2X::SetUpFrames()
{
//stand01, stand02... walk01 etc.
//First lets see how many key frames there are..
e.g. walk, run, stand etc.
m_Keys.numKeys = 0;
char strName[16] = {0};
char strLastName[16] = {0};
char strVeryFirstName[16] = {0};
for(int
iFrame=0; iFrame< m_Md2Header.numFrames; iFrame++)
{
strcpy(strName, m_pFrames[iFrame].name);
int stringLength = strlen(
strName );
for(int
i=0; i< stringLength; i++)
{
// a:97 A:65 z:122 Z:90
if( (strName[i] < 'A') ||
(strName[i] > 'z' ) )
{
// Its an integer if we
are here.
strName[i] = '\0';
if( strcmp(
strLastName, strName ) )
{
strcpy(strLastName, strName);
m_Keys.numKeys++;
}
if( !strcmp(
strVeryFirstName, "" ) )
strcpy( strVeryFirstName, strName );
break;
}
}
}
// Now that we are here, we know how many of each
key frame there
// are, e.g. there are 4 for stand, 6 for walk
etc.
//m_Keys.numKeys--;
m_Keys.pKey = new stKeyFrame[ m_Keys.numKeys
];
strcpy( strName, "");
strcpy( strLastName, strVeryFirstName);
//strcpy(strLastName, "");
int curKey = 0;
m_Keys.pKey[0].start = 0;
strcpy( m_Keys.pKey[0].szName, strVeryFirstName );
for(iFrame=0; iFrame< m_Md2Header.numFrames;
iFrame++)
{
strcpy(strName, m_pFrames[iFrame].name);
int stringLength = strlen(
strName );
for(int
i=0; i< stringLength; i++)
{
// a:97 A:65 z:122 Z:90
if( (strName[i] < 'A') ||
(strName[i] > 'z' ) )
{
// Its an integer if we
are here.
strName[i] = '\0';
if( strcmp(
strLastName, strName ) )
{
m_Keys.pKey[curKey].end = iFrame-1;
curKey++;
m_Keys.pKey[curKey].start = iFrame;
strcpy(strLastName, strName);
strcpy(m_Keys.pKey[curKey].szName, strName);
}
else
{
m_Keys.pKey[curKey].end = iFrame;
}
break;
}
}
}
}
void
CMD2X::SetUpDX()
{
/***************************************************************************/
/* Data is transfered into the directX vertex
buffers etc. */
/***************************************************************************/
int numFaces = m_Md2Header.numTriangles;
// Create a vertex buffer for a single model
frame.. all frames are the same size.
g_pD3DDevice->CreateVertexBuffer( numFaces * 3 *
sizeof(my_vertex), 0, m_vertex_description, D3DPOOL_MANAGED, &m_vb );
}
bool
CMD2X::Timer(float* t)
{
float delay = 0.2f;
// 0.2 of a second between changes. ~Speed of your
models animation~
float time = GetTickCount();
m_elapsedTime = time - m_lastTime;
m_elapsedTime = m_elapsedTime /1000.0f; // convert to seconds.
m_elapsedTime = m_elapsedTime / delay; // make
into a percentage of 100 e.g. 0->1
*t
= m_elapsedTime;
if( m_elapsedTime > 1.0f )
{
m_lastTime = time;
m_elapsedTime = 0.0f;
*t = m_elapsedTime;
return
true;
}
return false;
}
void
CMD2X::SetDXVertices(UINT iAnimKey)
{
// First Create the position of our new verts
using
// p(t) = p0 + t(p1 - p0);
// For those who are sharp to the eye, well its
arranged
// this way, as if you change from a walk to a
death, or run
// etc, it will change gradually... not jump...
creates a really
// smooth effect.
float t;
if( Timer(&t) )
{
m_curFrame = m_nextFrame;
m_nextFrame = (m_nextFrame + 1);
if( m_curAnimKey != iAnimKey )
{
m_nextFrame = m_Keys.pKey[ iAnimKey ].start;
// (curFrame + 1);
m_curAnimKey = iAnimKey;
}
}
if( m_curFrame == m_nextFrame )
m_nextFrame++;
if( m_nextFrame > m_Keys.pKey[ iAnimKey
].end)
m_nextFrame = m_Keys.pKey[ iAnimKey ].start;
// Copy our array which is in computer memory over
to the directX memory.. using that pointer we
// just created etc.
unsigned char
*temp_pointer_vb;
m_vb->Lock(0,0,
&temp_pointer_vb, 0);
my_vertex* p_mem = (my_vertex*)temp_pointer_vb;
int numFaces = m_Md2Header.numTriangles;
stMd2Vertices* pCurFrame = m_pFrames[m_curFrame].pFinalVerts;
stMd2Vertices* pNexFrame = m_pFrames[m_nextFrame].pFinalVerts;
for(int p=0;
p< numFaces; p++)
{
for(int
c=0; c<3; c++) // 3 sides to each face (e.g.
triangle).
{
int index =
m_pTriangles[p].vertexIndex[c];
float x1 = pCurFrame[index].vertex[0];//x
float y1 = pCurFrame[index].vertex[1];//y
float z1 = pCurFrame[index].vertex[2];//z
float x2 = pNexFrame[index].vertex[0];//x
float y2 = pNexFrame[index].vertex[1];//y
float z2 = pNexFrame[index].vertex[2];//z
p_mem[p*3+c].x = x1 + t * (x2 - x1);
p_mem[p*3+c].y = y1 + t * (y2 - y1);
p_mem[p*3+c].z = z1 + t * (z2 - z1);
int texIndex =
m_pTriangles[p].texIndex[c];
p_mem[p*3+c].tu = m_pTexCoords[ texIndex ].u / 256.0f;
p_mem[p*3+c].tv = m_pTexCoords[ texIndex ].v / 256.0f;
}
}
m_vb->Unlock();
}
void
CMD2X::Animate(UINT iAnimKey)
{
// Check to make sure that the iAnimKey is within
range.
iAnimKey = iAnimKey % m_Keys.numKeys;
SetDXVertices(iAnimKey);
}
void
CMD2X::RenderFrame()
{
unsigned int
numFaces = m_Md2Header.numTriangles;
// Okay at this point... our graphics card has our
vertices stored in it... we've just copied
// them over :) Some stuff to setup or graphics
card!
// Turn off lighting becuase we are specifying
that our vertices have colour
g_pD3DDevice->SetRenderState(D3DRS_LIGHTING, FALSE);
g_pD3DDevice->SetTextureStageState(0, D3DTSS_COLOROP, D3DTOP_SELECTARG1);
g_pD3DDevice->SetTextureStageState(0,D3DTSS_COLORARG1, D3DTA_TEXTURE);
// Draw our triangle.
g_pD3DDevice->SetStreamSource(0, m_vb, sizeof(my_vertex));
g_pD3DDevice->SetVertexShader(m_vertex_description);
g_pD3DDevice->SetTexture(0,m_pTexture);
// number of
primitives
// starting
vertex |
//
| |
//
\|/ \|/
//
| |
g_pD3DDevice->DrawPrimitive(D3DPT_TRIANGLELIST, 0, numFaces);
}
void
CMD2X::Release()
{
m_vb->Release();
// We can delete all our allocated memory as its
now been transfered over
// to the directX vertex buffer.
for(int
iFrame; iFrame< m_Md2Header.numFrames; iFrame++)
{
delete[]
m_pFrames[iFrame].pFinalVerts;
}
delete[] m_pSkins;
delete[] m_pTexCoords;
delete[] m_pTriangles;
delete[] m_pFrames;
delete[] m_Keys.pKey;
} |
